BlogBuilding a Modal Route with React Router

Building a Modal Route with React Router

beautiful-bird

📸

Pexels

I don’t know about you, but I love modals. Specifically, when they’re used to display content without navigating away from the current page.

And today, I’ll show you how to create a modal route in React with the help of the react-router-dom  library.

if some of you are not understanding what we are going to build, then you can see the stackblitz  live demo example.

Use Case 🧐

  • Suppose you have a list of items and you want to show the details of the item in a modal and without navigating to a new page.
  • You want to show a form in a modal and submit the form without navigating to a new page.

Imagine how cool it would be to navigating to a new link without leaving the current page.

Okay enough talking, let’s start.

Getting Started 📌

I’m assuming you have a basic understanding of React  and React Router . If not, I recommend checking out the official documentation. and also you have a basic react project setup.

Step 1 - Setup React Router

First, let’s set up the React Router in our project. We’ll be use the createBrowserRouter for define our routes.

App.js
import * as React from 'react'
import { Dialog } from '@reach/dialog'
import {
  createBrowserRouter,
  Link,
  Outlet,
  RouterProvider,
  useNavigate,
  useParams,
} from 'react-router-dom'

import '@reach/dialog/styles.css'

import { getImageById, IMAGES } from './images'

const router = createBrowserRouter([
  {
    path: '/',
    Component: Layout,
    children: [
      {
        path: '/',
        Component: Home,
      },
      {
        path: 'gallery',
        Component: Gallery,
        children: [
          {
            path: 'img/:id',
            Component: ImageView,
          },
        ],
      },
    ],
  },
])

export default function App() {
  return <RouterProvider router={router} />
}

Step 2 - Create the Layout

The Layout component acts as the main structure of our application. It includes a navigation menu and an Outlet to render child routes.

Layout.js
export function Layout() {
  return (
    <div>
      <h1>Outlet Modal Example</h1>
      <p>
        This is a modal example using `createBrowserRouter` that drives modal
        displays through URL segments. The modal is a child route of its parent
        and renders in the `Outlet`.
      </p>
      <div>
        <nav>
          <ul>
            <li>
              <Link to='/'>Home</Link>
            </li>
            <li>
              <Link to='/gallery'>Gallery</Link>
            </li>
          </ul>
        </nav>
        <hr />
      </div>
      <Outlet />
    </div>
  )
}

Now we have to create the Home Page.

Step 3 - Defining the Home Page

The Home page is the default route of our application. It contains a link to the Gallery route. It’s will be just a basic page with a link to the Gallery route.

Home.js
export function Home() {
  return (
    <div>
      <h2>Home</h2>
      <p>
        Click over to the <Link to='/gallery'>Gallery</Link> route to see the
        modal in action.
      </p>
      <Outlet />
    </div>
  )
}

Step 4 - Create the Gallery Component

The Gallery component displays a grid of images. Each image is a link that opens a modal by changing the URL to a child route.

Gallery.js
export function Gallery() {
  return (
    <div style={{ padding: '0 24px' }}>
      <h2>Gallery</h2>
      <p>
        Click on an image to open a modal. You'll notice that the URL changes,
        and you still see this route behind the modal. The modal is a child
        route of <pre style={{ display: 'inline' }}>"/gallery"</pre>.
      </p>
      <div
        style={{
          display: 'grid',
          gridTemplateColumns: 'repeat(auto-fit, minmax(200px, 1fr))',
          gap: '24px',
        }}
      >
        {IMAGES.map((image) => (
          <Link key={image.id} to={`img/${image.id}`}>
            <img
              width={200}
              height={200}
              style={{
                width: '100%',
                aspectRatio: '1 / 1',
                height: 'auto',
                borderRadius: '8px',
              }}
              src={image.src}
              alt={image.title}
            />
          </Link>
        ))}
        <Outlet />
      </div>
    </div>
  )
}

And finally, we have to create the modal component to display the image.

Step 5 - The Modal Component

The ImageView component represents the modal itself. And for modal we gonna use the @reach/dialog package.

bash filename="terminal" copy npm install @reach/dialog

And here is the code for the ImageView component.

ImageView.js
export function ImageView() {
  let navigate = useNavigate();
  let { id } = useParams<"id">();
  let image = getImageById(Number(id));
  let buttonRef = React.useRef<HTMLButtonElement>(null);

  function onDismiss() {
    navigate(-1);
  }

  if (!image) {
    throw new Error(`No image found with id: ${id}`);
  }

  return (
    <Dialog
      aria-labelledby="label"
      onDismiss={onDismiss}
      initialFocusRef={buttonRef}
    >
      <div
        style={{
          display: "grid",
          justifyContent: "center",
          padding: "8px 8px",
        }}
      >
        <h1 id="label" style={{ margin: 0 }}>
          {image.title}
        </h1>
        <img
          style={{
            margin: "16px 0",
            borderRadius: "8px",
            width: "100%",
            height: "auto",
          }}
          width={400}
          height={400}
          src={image.src}
          alt=""
        />
        <button
          style={{ display: "block" }}
          ref={buttonRef}
          onClick={onDismiss}
        >
          Close
        </button>
      </div>
    </Dialog>
  );
}

Woohoo! 🥳 You have successfully implemented the modal using @reach/dialog and react-router-dom.

Trust me, it’s a great feeling to create something like this. 🚀

Complete Code

If you need the complete code, you can find it here  and find the live demo stackblitz  here.

Thanks for reading! 🙌
